The mount body with direct e3D Titan Extruder support.
All parts of original Heavy Duty and modules are compatible with this mount body.
Supports up to Nema 17 34mm stepper motors without problems (Tested on  Ender 3)

Hello, this project is no longer supported, check my new design https://www.thingiverse.com/thing:4778095
This is adapted version of the popular Heavy Duty mount with dual 5015 blowers (https://www.thingiverse.com/thing:2494642) with direct installation E3D Titan Extruder + v6 hotend for CR-10-like printers.
Yes, I know that exist Titan-direct mounts, but my design uses the standard installation of the radiator in the extruder, and not using fittings.
Requires 5 M3 nut&bolts to assemble
The BLTouch mount is rigidly fixed, a hole for the cable is reserved for it
BLTouch Offset: X: -37 Y: -35
This mount uses NEMA 17 21mm-24mm stepper motors, for more thick ones there is a mounting version without a left blower 5015.
For cooling the radiator you can use a standard 30mm fan and 40mm through mine adapter (included).
There is also a * .step file for editing to fit your needs, share your remixes! :D
Updates:
04/28/2020 - Added an adapter for a 40mm fan at an angle (based on https://www.thingiverse.com/thing:506958)…

CR-10 Heavy Duty Modular E3D V6 Mount
I have started a Shapeways shop where you can get these parts printed. I have special versions of the V6 mount designed for Aluminium. At the moment the shop doesn't have much as I'm still setting it up. It's also expensive to get aluminum prints but its an option for those who want it parts that will survive in an enclosure. If no one uses it i will get rid of it. Im just testing the idea outhttps://www.shapeways.com/shops/chito-1
This is a mount for the V6 hot-end by E3D that is stronger and more rigid than some of the mounts that are out there. This mount also comes with an array of possible options for any extra functionality as attachments on the sides.
The minimum you will need to print out is the body and one of the faceplates. There are a variety of wings for different combinations, additions and customizations.
NOTE: Only left side parts are in the library of wings. To print a wing for the right side simply mirror the part in your slicer.
Current modules
5015 fan…
