This is a mount to suit a Bondtech/ V6 direct drive, incorporating a hotend shroud and duct for any 40mm axial fan.
NB. This is not compatible with the stock extruder stepper motor. You will need a pancake stepper or it'll hit the X limit switch housing.
In  response to feedback the following improvements have been implemented:
All sections of the mounting plate are thicker and stronger. There is also a clamp to secure the mounting plate to the X carriage plate, eliminating any movement due to the moment of the stepper and extruder.
The duct is now secured from both sides eliminating any twist.
The 5015 blower is now secured with both fixings.
There is a notch to accommodate the fixing lugs on the bodies of some 5015 blowers.
The BLTouch can be removed and replaced with a single bolt without disturbing the Z offset.
The effective part cooling nozzle geometry remains identical.
Hardware:
M3 x 8mm  6off
M3 x 10mm 4off
M3 x 12mm 2off
M3 x 12mm 2off
M3 x 25mm 2off
M3 Nyloc nut 10off
M3 nut (standard) 1off
M3 washer…
